GreeningATL reflects our commitment to achieve the triple bottom line — people, planet and profits –while working to become the world’s “greenest” airport. Through innovation and cutting-edge technologies, Hartsfield-Jackson strategically incorporates a common-sense approach to manage our resources to ensure a sustainable future.
To that end, the Department of Aviation has pledged to plan, build, operate and maintain an integrative approach to achieve measurable results that propel our community, stakeholders and the environment. GreeningATL is where thinking “green” becomes routine.
The Department of Aviation is a national leader in airfield pavement recycling. Pavement recycling began in 1999 with the reconstruction of Runway 9R-27L. Aviation contractors neatly cut the pavement into large slabs and placed them at a storage site proximate to the airfield. When future projects require the use of a large quantity of fill, the slabs will be demolished into smaller pieces for subsequent incorporation into the deepest areas of fill. Historically, the Department has recycled more than 675,000 tons of concrete and used recycled pavement in fill sections that were required for the Runway 10-28 and South Complex site preparation projects.
Paper Products in Restrooms
Given the high levels of passenger and aircraft activity at Hartsfield-Jackson, as well as the size of our Central Passenger Terminal Complex (CPTC), we recognize that opportunities exist to minimize waste. We have made tremendous progress in source reduction by using some innovative techniques associated with paper products in terminal restrooms. By switching to automatic dispense paper towels from folded ones, approximately 240,000 pounds of paper are saved annually. Another innovation is through changing types of toilet paper used to coreless rolls. By using coreless rolls, approximately 140,000 pounds of paper are saved annually.
Composting is performed at the landscape shop at the former Northwest Airlines hangar. The process combines nitrogen from green materials (flowers and grass clippings) and carbon from brown materials (dried leaves and straw). These materials are turned regularly and eventually break down into decomposed organic matter known as compost. All of the materials are derived from routine work at the airport (i.e. cutting grass, raking leaves, recycling flowers). The materials are added to the compost pile throughout the year. The compost is used as a soil amendment in the various seasonal color beds and containers throughout the Airport property.
Preconditioned Air and 400 Hertz Power
When aircraft are parked at the gate, they need a source to power instruments and interior lighting and provide conditioned air in the cabin. The most efficient and environmentally friendly way to do this is by providing preconditioned air and 400 Hertz (Hz) power connections at each aircraft parking position. Without these connections, aircraft are required to either run their auxiliary power units (a small jet fuel engine located under the aircraft tail) or use a diesel-powered ground power unit. There are 199 aircraft parking positions in the Central Passenger Terminal Complex. Of the 199 positions, approximately 90 percent are equipped with preconditioned air and 400 Hz power.
Clean Construction Equipment
The Department of Aviation became one of the first airport sponsors in the United States to require contractors working on large projects, especially those moving large quantities of fill, to use “clean” construction equipment. Such equipment features low emissions production and uses the EPA’s nonroad diesel emissions standards. Besides specifying the use of clean equipment, ATL became the first airport in the country to use an overland conveyor to transport large quantities of fill material. The conveyor transported approximately 20 million cubic yards of fill material during the construction of Runway 10-28. Without the conveyor, approximately 2.5 million dump truck round trips would have been required to transport the material.
Automatic Vehicle Identification (AVI) System
The Ground Transportation Center (GTC) is served by taxis and shuttle buses from hotels and other facilities. In an effort to eliminate excessive engine dwell times from these vehicles, the Airport implemented an Automatic Vehicle Identification (AVI) system. As part of the AVI system, all service vehicles entering the Airport GTC are equipped with transponders. Consequently, vehicle operators can be billed based on the number of times they access and the amount of time they spend at the GTC. This billing system creates a disincentive to dwell excessively at the GTC, thereby reducing emissions.
Calendar year 2009 marked the first full year of AVI system availability. Since it became operational, the system has recorded approximately 1.5 million vehicle entries into the GTC.
In the spring of 2007, the Department of Aviation commissioned the nation’s first end-around taxiway, Taxiway “V.” Instead of arriving aircraft landing on Runway 26R and taxiing into the Central Passenger Terminal Complex after crossing Runway 26L, these aircraft now taxi around the end of Runway 26L. Due to a special design of the taxiway, aircraft can now depart on Runway 26L without incurring delays created by the Runway 26R arrivals crossing the runway. This special design and use of the taxiway has boosted Runway 26L’s departure rate, and an increased departure rate leads to reduced delays and emissions.
Rental Car Center and SkyTrain
In December 2009, the Department of Aviation opened its new Rental Car Center. An electric-powered automated people mover system known as the SkyTrain links the Rental Car Center to additional parking and the Airport terminal building. The SkyTrain also serves the Gateway, which includes the Georgia International Convention Center, the Atlanta Airport Marriott and SpringHill Suites.
The SkyTrain replaced diesel-powered shuttle buses, resulting in reduced traffic on area roadways, reduced emissions created from transferring cars between on-Airport and off-Airport sites, and convenient transportation to the Gateway.
Low Flow Rest Room Fixtures in the Central Passenger Terminal Complex
In response to record drought conditions in 2007, the Department began a major water conservation initiative. Specifically, 630 toilets with a 1.6-gallon-per-flush rating were replaced with 1.28-gallon-per flush models. In addition, 1,200 one-gallon-per-flush urinals were replaced with 0.5-gallon-per-flush units.
From April 2007 to March 2008, the Airport used 324.9 million gallons of water. The following year, water usage dropped by nearly 8 percent. Water consumption dropped by an additional 61.2 million gallons – 20.4 percent – between April 2009 and March 2010.
The conversion to low-flow restroom fixtures throughout the Airport is one reason for the savings.
Xeriscape landscaping is designed specifically to cope with dry conditions and for water conservation. Xeriscape plant material is installed in 4,500 square feet of seasonal color beds throughout the Airport property. The number of active sites varies throughout the year based on the season. Xeriscape planting material at the Airport is a good choice because of Atlanta’s climate; the plantings are well adapted to heat and survive on little rainfall once established.
Department of Aviation maintenance crews installed three, 2,500-gallon water cisterns, which capture water runoff from a roof. The water collected from the cisterns is used to irrigate the xeriscaped areas, as well as other areas. From May to August, the maintenance unit uses approximately 8,000 gallons per month of harvested rainwater. During the cooler months and depending on rainfall events, not as much water is needed or used from the cisterns.
The Sams Lake wetlands restoration area opened to the public in 2008 as a wildlife sanctuary. The Department of Aviation partnered with the Southern Conservation Trust and opened the 56.6-acre wetlands restoration area at a cost of $5 million. It features a reconstructed stream, bat houses, observation decks and a walking trail. Several small dams create three ponds, where bass and nesting birds flourish. The wetlands also are home to turkeys, hawks, blue herons, crows, toads, egrets and deer. To ensure that Sams Lake is viable long term, the Airport monitors wetland success criteria to anchor the site’s ecosystem. Sams Lake is in Fayette County, south of the Airport.
The Department of Aviation has partnered with the Clayton County Water Authority in the restoration of Jesters Creek. Because of the stream restoration project monitoring and maintenance activities, a strong and viable habitat has taken hold. Jesters Creek is in Clayton County, south of the Airport.
Building owners committed to the environment and sustainability look to design buildings or renovation projects that achieve Leadership in Energy and Sustainability Design (LEED) certification as published by the United States Green Building Council (USGBC). Four levels of LEED certification exist: Certified, Silver, Gold and Platinum. The LEED certification process is a rigorous one, requiring engineers and architects to incorporate specific, sustainability-enhancing elements into a design. The USGBC then evaluates designs using a scoring system to determine the level of LEED certification the design earns.
In July 2007, the Department of Aviation was awarded its first LEED certification for Fire Station 33, which is adjacent to Runway 10-28. It was certified at the Silver level.
A second fire station, Fire Station 24, is also LEED certified. This fire station, located in the northeast corner of the airfield, underwent a major remodeling completed in 2010.
The Maynard H. Jackson Jr. International Terminal, completed in 2012, achieved a LEED Gold certification.
CPTC Chiller Replacement Project
The Terminal Central Utilities Plant (T-CUP), which was built in 1978 as part of the original Central Passenger Terminal Complex (CPTC) construction, contains upgraded high-efficiency equipment. Before the upgrade, the T-CUP had two 30-year-old steam-driven chillers. Two natural gas-fired boilers generated the steam used to drive the chillers. The steam-driven chillers were replaced by two electric chillers, thus eliminating the need to use natural gas-fired boilers to generate steam. The sustainability paybacks of the project are now apparent. During the ozone season of 2007 (May through September), approximately 112.8 million cubic feet (MMCF) of natural gas was used within the T-CUP, mainly to generate steam for the old chillers. During the ozone season of 2008, 30.8 MMCF of natural gas was used within the T-CUP, a 73 percent reduction in natural gas usage. In 2009, only 1 MMCF of natural gas was used, realizing a 99 percent reduction from 2007 usage numbers.
Light-Emitting Diode Airfield Lights
Numerous taxiways incorporate light-emitting diode (LED) edge lights to reduce electricity consumption. More than 3,000 LED edge and guard lights have been installed. The Department of Aviation now requires LED lighting on all new or reconstructed taxiways. An LED airfield light fixture uses approximately 50 percent less electricity than a similar incandescent fixture. The Department is working with a prominent lighting provider to develop edge lighting that is even more efficient than currently available.
